Icon LinkRun Sequencer Validator

Icon LinkTypical Setup

The validator setup will consist of a Fuel Sequencer, Sidecar, and a connection to an Ethereum Mainnet Node.

fuel sequencer validator

Icon LinkPrerequisites

The guide assumes that Golang is installed in order to run Cosmovisor. We recommend installing version 1.21+.

Icon LinkRun an Ethereum Mainnet Full Node

To ensure the highest performance and reliability of the Sequencer infrastructure, running your own Ethereum Mainnet full node is a requirement. Avoiding the use of third-party services for Ethereum node operations significantly helps the Sequencer network's liveness. Please note these recommended node configurations:

--syncmode=snap
--gcmode=full

Icon LinkConfigure the Sequencer

Obtain binary and genesis from this repository:

Download the right binary based on your architecture to $GOPATH/bin/ with the name fuelsequencerd:

  • echo $GOPATH to ensure it exists. If not, go might not be installed.
  • mkdir $GOPATH/bin/ if the directory does not exist.
  • wget <url/to/binary> to download the binary, or any equivalent approach.
  • cp <binary> $GOPATH/bin/fuelsequencerd

Try the binary:

fuelsequencerd version  # expect seq-mainnet-1.2-improved-sidecar

Initialise the node directory, giving your node a meaningful name:

fuelsequencerd init <node-name> --chain-id seq-mainnet-1

Copy the downloaded genesis file to ~/.fuelsequencer/config/genesis.json:

cp <path/to/genesis.json> ~/.fuelsequencer/config/genesis.json

Configure the node (part 1: ~/.fuelsequencer/config/app.toml):

  • Set minimum-gas-prices = "10fuel".
  • Configure [sidecar]:
    • Ensure that enabled = true.
    • Ensure that address is where the Sidecar will run.
  • Configure [api]:
    • Set swagger=true (optional).
    • Set rpc-max-body-bytes = 1153434 (optional - relevant for public REST).
  • Configure [commitments]:
    • Set api-enabled = true (optional - relevant for public REST).
  • Configure [state-sync]:
    • Set snapshot-interval = 1000 (optional - to provide state-sync service).
  • Configure:
    • Set rpc-read-timeout = 10 (optional - relevant for public REST).
    • Set rpc-write-timeout = 0 (optional - relevant for public REST).
Icon InfoCircle

WARNING: leaving the [commitments] API accessible to anyone can lead to DoS! It is highly recommended to handle whitelisting or authentication by a reverse proxy like Traefik Icon Link for gRPC if the commitments API is enabled.

Configure the node (part 2: ~/.fuelsequencer/config/config.toml):

  • Configure [p2p]:
  • Configure [mempool]:
    • Set max_tx_bytes = 1258291 (1.2MiB)
    • Set max_txs_bytes = 23068672 (22MiB)
  • Configure [rpc]:
    • Set max_body_bytes = 1153434 (optional - relevant for public RPC).
Icon InfoCircle

Note: Ensuring consistent CometBFT mempool parameters across all network nodes is important to reduce transaction delays. This includes mempool.size, mempool.max_txs_bytes, and mempool.max_tx_bytes in config.toml Icon Link and minimum-gas-prices in app.toml Icon Link, as pointed out above.

Icon LinkInstall Cosmovisor

To install Cosmovisor, run go install cosmossdk.io/tools/cosmovisor/cmd/cosmovisor@latest

Set the environment variables:

echo "# Setup Cosmovisor" >> ~/.zshrc
echo "export DAEMON_NAME=fuelsequencerd" >> ~/.zshrc
echo "export DAEMON_HOME=$HOME/.fuelsequencer" >> ~/.zshrc
echo "export DAEMON_ALLOW_DOWNLOAD_BINARIES=true" >> ~/.zshrc
echo "export DAEMON_LOG_BUFFER_SIZE=512" >> ~/.zshrc
echo "export DAEMON_RESTART_AFTER_UPGRADE=true" >> ~/.zshrc
echo "export UNSAFE_SKIP_BACKUP=true" >> ~/.zshrc
echo "export DAEMON_SHUTDOWN_GRACE=15s" >> ~/.zshrc

# You can check https://docs.cosmos.network/main/tooling/cosmovisor for more configuration options.

Apply to your current session: source ~/.zshrc

echo "# Setup Cosmovisor" >> ~/.bashrc
echo "export DAEMON_NAME=fuelsequencerd" >> ~/.bashrc
echo "export DAEMON_HOME=$HOME/.fuelsequencer" >> ~/.bashrc
echo "export DAEMON_ALLOW_DOWNLOAD_BINARIES=true" >> ~/.bashrc
echo "export DAEMON_LOG_BUFFER_SIZE=512" >> ~/.bashrc
echo "export DAEMON_RESTART_AFTER_UPGRADE=true" >> ~/.bashrc
echo "export UNSAFE_SKIP_BACKUP=true" >> ~/.bashrc
echo "export DAEMON_SHUTDOWN_GRACE=15s" >> ~/.bashrc

# You can check https://docs.cosmos.network/main/tooling/cosmovisor for more configuration options.

Apply to your current session: source ~/.bashrc

You can now test that cosmovisor was installed properly:

cosmovisor version

Initialise Cosmovisor directories (hint: whereis fuelsequencerd for the path):

cosmovisor init <path/to/fuelsequencerd>

At this point cosmovisor run will be the equivalent of running fuelsequencerd, however you should not run the node for now.

Icon LinkConfigure State Sync

State Sync allows a node to get synced up quickly.

To configure State Sync, you will need to set these values in ~/.fuelsequencer/config/config.toml under [statesync]:

  • enable = true to enable State Sync
  • rpc_servers = ...
  • trust_height = ...
  • trust_hash = ...

The last three values can be obtained from the explorer Icon Link.

You will need to specify at least two comma-separated RPC servers in rpc_servers. You can either refer to the list of alternate RPC servers above or use the same one twice.

Icon LinkRun the Sidecar

At this point you should already be able to run fuelsequencerd start-sidecar with the right flags, to run the Sidecar. However, it is highly recommended to run the Sidecar as a background service.

It is also very important to ensure that you provide all the necessary flags when running the Sidecar to ensure that it can connect to an Ethereum node and to the Sequencer node, and is also accessible by the Sequencer node. The most important flags are:

  • host: host for the gRPC server to listen on
  • port: port for the gRPC server to listen on
  • eth_ws_url: Ethereum node WebSocket endpoint
  • eth_rpc_url: Ethereum node RPC endpoint
  • eth_contract_address: address in hex format of the contract to monitor for logs. This MUST be set to 0xBa0e6bF94580D49B5Aaaa54279198D424B23eCC3.
  • sequencer_grpc_url: Sequencer node gRPC endpoint

Icon LinkLinux

On Linux, you can use systemd to run the Sequencer in the background. Knowledge of how to use systemd is assumed here.

Here's an example service file with some placeholder (<...>) values that must be filled-in:

[Unit]
Description=Sidecar
After=network.target

[Service]
Type=simple
User=<USER>
ExecStart=<HOME>/go/bin/fuelsequencerd start-sidecar \
    --host "0.0.0.0" \
    --sequencer_grpc_url "127.0.0.1:9090" \
    --eth_ws_url "<ETHEREUM_NODE_WS>" \
    --eth_rpc_url "<ETHEREUM_NODE_RPC>" \
    --eth_contract_address "0xBa0e6bF94580D49B5Aaaa54279198D424B23eCC3"
Restart=on-failure
RestartSec=3
LimitNOFILE=4096

[Install]
WantedBy=multi-user.target

Icon LinkMac

On Mac, you can use launchd to run the Sequencer in the background. Knowledge of how to use launchd is assumed here.

Here's an example plist file with some placeholder ([...]) values that must be filled-in:

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd">
<plist version="1.0">
<dict>
    <key>Label</key>
    <string>fuel.sidecar</string>

    <key>ProgramArguments</key>
    <array>
        <string>/Users/[User]/go/bin/fuelsequencerd</string>
        <string>start-sidecar</string>
        <string>--host</string>
        <string>0.0.0.0</string>
        <string>--sequencer_grpc_url</string>
        <string>127.0.0.1:9090</string>
        <string>--eth_ws_url</string>
        <string>[ETHEREUM_NODE_WS]</string>
        <string>--eth_rpc_url</string>
        <string>[ETHEREUM_NODE_RPC]</string>
        <string>--eth_contract_address</string>
        <string>0xBa0e6bF94580D49B5Aaaa54279198D424B23eCC3</string>
    </array>

    <key>UserName</key>
    <string>[User]</string>

    <key>KeepAlive</key>
    <dict>
        <key>SuccessfulExit</key>
        <false/>
    </dict>

    <key>HardResourceLimits</key>
    <dict>
        <key>NumberOfFiles</key>
        <integer>4096</integer>
    </dict>

    <key>StandardOutPath</key>
    <string>/Users/[User]/Library/Logs/fuel-sidecar.out</string>
    <key>StandardErrorPath</key>
    <string>/Users/[User]/Library/Logs/fuel-sidecar.err</string>
</dict>
</plist>

Icon LinkRun the Sequencer

At this point you should already be able to run cosmovisor run start to run the Sequencer. However, it is highly recommended to run the Sequencer as a background service.

Some examples are provided below for Linux and Mac. You will need to replicate the environment variables defined when setting up Cosmovisor.

Icon LinkLinux

On Linux, you can use systemd to run the Sequencer in the background. Knowledge of how to use systemd is assumed here.

Here's an example service file with some placeholder (<...>) values that must be filled-in:

[Unit]
Description=Sequencer Node
After=network.target

[Service]
Type=simple
User=<USER>
ExecStart=/home/<USER>/go/bin/cosmovisor run start
Restart=on-failure
RestartSec=3
LimitNOFILE=4096

Environment="DAEMON_NAME=fuelsequencerd"
Environment="DAEMON_HOME=/home/<USER>/.fuelsequencer"
Environment="DAEMON_ALLOW_DOWNLOAD_BINARIES=true"
Environment="DAEMON_LOG_BUFFER_SIZE=512"
Environment="DAEMON_RESTART_AFTER_UPGRADE=true"
Environment="UNSAFE_SKIP_BACKUP=true"
Environment="DAEMON_SHUTDOWN_GRACE=15s"

[Install]
WantedBy=multi-user.target

Icon LinkMac

On Mac, you can use launchd to run the Sequencer in the background. Knowledge of how to use launchd is assumed here.

Here's an example plist file with some placeholder ([...]) values that must be filled-in:

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd">
<plist version="1.0">
<dict>
    <key>Label</key>
    <string>fuel.sequencer</string>

    <key>ProgramArguments</key>
    <array>
        <string>/Users/[User]/go/bin/cosmovisor</string>
        <string>run</string>
        <string>start</string>
    </array>

    <key>UserName</key>
    <string>[User]</string>

    <key>EnvironmentVariables</key>
    <dict>
        <key>DAEMON_NAME</key>
        <string>fuelsequencerd</string>
        <key>DAEMON_HOME</key>
        <string>/Users/[User]/.fuelsequencer</string>
        <key>DAEMON_ALLOW_DOWNLOAD_BINARIES</key>
        <string>true</string>
        <key>DAEMON_LOG_BUFFER_SIZE</key>
        <string>512</string>
        <key>DAEMON_RESTART_AFTER_UPGRADE</key>
        <string>true</string>
        <key>UNSAFE_SKIP_BACKUP</key>
        <string>true</string>
        <key>DAEMON_SHUTDOWN_GRACE</key>
        <string>15s</string>
    </dict>

    <key>KeepAlive</key>
    <dict>
        <key>SuccessfulExit</key>
        <false/>
    </dict>

    <key>HardResourceLimits</key>
    <dict>
        <key>NumberOfFiles</key>
        <integer>4096</integer>
    </dict>

    <key>StandardOutPath</key>
    <string>/Users/[User]/Library/Logs/fuel-sequencer.out</string>
    <key>StandardErrorPath</key>
    <string>/Users/[User]/Library/Logs/fuel-sequencer.err</string>
</dict>
</plist>

Icon LinkCreating an Account

To run a validator, you will need to have a Sequencer account address. Generate an address with a key name:

fuelsequencerd keys add <NAME> # for a brand new key

# or

fuelsequencerd keys add <NAME> --recover # to create from a mnemonic

This will give you an output with an address (e.g. fuelsequencer1l7qk9umswg65av0zygyymgx5yg0fx4g0dpp2tl) and a private mnemonic, if you generated a brand new key. Store the mnemonic safely.

Fuel Sequencer addresses also have an Ethereum-compatible (i.e. hex) format. To generate the hex address corresponding to your Sequencer address, run the following:

fuelsequencerd keys parse <ADDRESS>

This will give an output in this form:

bytes: FF8162F37072354EB1E222084DA0D4221E93550F
human: fuelsequencer

Adding the 0x prefix to the address in the first line gives you your Ethereum-compatible address, used to deposit into and interact with your Sequencer address from Ethereum. In this case, it's 0xFF8162F37072354EB1E222084DA0D4221E93550F.

Icon LinkFunding the Account

Ensure your mainnet Ethereum account (EOA) has sufficient ETH to cover gas fees and FUEL tokens to transfer to your Sequencer account.

Icon LinkImportant Addresses

Icon LinkToken Approval

Before proceeding, you must approve the Fuel token contract to allow the transfer of tokens.

In the Fuel Token Etherscan contract UI Icon Link, use the approve (0x095ea7b3) function:

  • Spender (address): Set this to the Sequencer Interface (Bridge) address: 0xca0c6B264f0F9958Ec186eb2EAa208966187D866 Icon Link.

  • Value (uint256): Enter the number of tokens to approve, including 9 additional decimal places. For unlimited approval, use:

    0xffffffffffffffffffffffffffffffffffffffffffffffffffffffffffffffff

Mainnet Etherscan Approval UI

Icon LinkBridging Tokens

To bridge tokens, connect your Ethereum wallet by clicking "Connect to Web3" in the top left. Then, use the depositFor (0x36efd6f) function to fund your sequencer account.

Transfer your FUEL tokens using the Sequencer Interface (Bridge)Etherscan UI Icon Link.

Mainnet Etherscan UI

  • Amount (uint256): Enter the number of tokens to send, including 9 additional decimal places.
  • Recipient address: Enter the Ethereum-compatible address you generated earlier (e.g., 0xFF8162F37072354EB1E222084DA0D4221E93550F).

Click "Write" to confirm the transaction. The transfer may take ~20 minutes to process.

Icon LinkVerifying Funds

To verify your funds, enter your sequencer account address (i.e. fuelsequencer1l7qk9umswg65av0zygyymgx5yg0fx4g0dpp2tl) in the mainnet block explorer Icon Link.

Mainnet Block Explorer

Icon InfoCircle

⚠ WARNING: Always test with a small transfer before bridging FUEL tokens.

Icon LinkCreate the Validator

To create the validator, a prerequisite is to have at least 1FUEL, with enough extra to pay for gas fees. You can check your balance from the explorer.

Once you have FUEL tokens, run the following to create a validator, using the name of the account that you created in the previous steps:

fuelsequencerd tx staking create-validator path/to/validator.json \
    --from <NAME> \
    --gas auto \
    --gas-prices 10fuel \
    --gas-adjustment 1.5 \
    --chain-id seq-mainnet-1

...where validator.json contains:

{
 "pubkey": {"@type":"/cosmos.crypto.ed25519.PubKey","key":"<PUBKEY>"},
 "amount": "1000000000fuel",
 "moniker": "<MONIKER>",
 "identity": "<OPTIONAL-IDENTITY>",
 "website": "<OPTIONAL-WEBSITE>",
 "security": "<OPTIONAL-EMAIL>",
 "details": "<OPTIONAL-DETAILS>",
 "commission-rate": "0.05",
 "commission-max-rate": "<MAX-RATE>",
 "commission-max-change-rate": "<MAX-CHANGE-RATE>",
 "min-self-delegation": "1"
}

...where the pubkey can be obtained using fuelsequencerd tendermint show-validator.

Icon LinkWhat to Expect

  • The Sequencer should show block syncing.
  • The Sidecar should show block extraction. Occasionally it also receives requests for events.

Icon LinkTendermint KMS

If you will be using tmkms, make sure that in the config:

  • Chain ID is set to seq-mainnet-1 wherever applicable
  • account_key_prefix = "fuelsequencerpub"
  • consensus_key_prefix = "fuelsequencervalconspub"
  • sign_extensions = true
  • protocol_version = "v0.34"

Icon LinkAdditional Advanced Configuration

Sidecar flags:

  • development: starts the sidecar in development mode.
  • eth_max_block_range: max number of Ethereum blocks queried at one go.
  • eth_min_logs_query_interval: minimum wait between successive queries for logs.
  • unsafe_eth_start_block: the Ethereum block to start querying from.
  • unsafe_eth_end_block: the last Ethereum block to query. Incorrect use can cause the validator to propose empty blocks, leading to slashing!
  • sequencer_path_to_cert_file: path to the certificate file of the Sequencer infrastructure for secure communication. Specify this value if the Sequencer infrastructure was set up using TLS.
  • sidecar_path_to_cert_file: path to the certificate file of the sidecar server for secure communication. Specify this value if you want to set up a sidecar server with TLS.
  • sidecar_path_to_key_file: path to the private key file of the sidecar server for secure communication. Specify this value if you want to set up a sidecar server with TLS.
  • prometheus_enabled: enables serving of prometheus metrics.
  • prometheus_listen_address: address to listen for prometheus collectors (default ":8081").
  • prometheus_max_open_connections: max number of simultaneous connections (default 3).
  • prometheus_namespace: instrumentation namespace (default "sidecar").
  • prometheus_read_header_timeout: amount of time allowed to read request headers (default 10s).
  • prometheus_write_timeout: maximum duration before timing out writes of the response (default 10s).

Sidecar client flags:

  • sidecar_grpc_url: the sidecar's gRPC endpoint.
  • query_timeout: how long to wait before the request times out.

Icon LinkReferences

Based on material from:
